Overview
1. 2x USB 2.0 | 8. USB 3.2 Gen 2 |
2. 2x USB 3.2 Gen 1 | 9. 2x USB 3.2 Gen 1 |
3. Headphone (3.5mm) | 10. Ethernet (RJ-45) |
4. Power button | 11. 6x Audio line-out (3.5mm) |
5. Microphone (3.5mm) | 12. Optional ports on expansion cards |
6. 4x USB 2.0 | 13. Power connector |
7. USB-C 3.2 Gen 2 |
Performance
Processor
Processor Family
10th Generation Intel® Core™ i7 / i9 or 11th Generation Intel Core i7 / i9 Processor
Processor**[1]
| Processor Name | Cores | Threads | Base Frequency | Max Frequency | Cache | Memory Support | Processor Graphics |
| Core i7-10700K | 8 | 16 | 3.8GHz | 5.1GHz | 16MB | DDR4-2933 | Intel UHD Graphics 630 |
| Core i7-10700KF | 8 | 16 | 3.8GHz | 5.1GHz | 16MB | DDR4-2933 | - |
| Core i7-11700K | 8 | 16 | 3.6GHz | 5.0GHz | 16MB | DDR4-3200 | Intel UHD Graphics 750 |
| Core i9-10850K | 10 | 20 | 3.6GHz | 5.2GHz | 20MB | DDR4-2933 | Intel UHD Graphics 630 |
| Core i9-10900K | 10 | 20 | 3.7GHz | 5.3GHz | 20MB | DDR4-2933 | Intel UHD Graphics 630 |
| Core i9-10900KF | 10 | 20 | 3.7GHz | 5.3GHz | 20MB | DDR4-2933 | - |
| Core i9-11900K | 8 | 16 | 3.5GHz | 5.3GHz | 16MB | DDR4-3200 | Intel UHD Graphics 750 |
| Core i9-11900KF | 8 | 16 | 3.5GHz | 5.3GHz | 16MB | DDR4-3200 | - |
Notes:
- 1 :Intel UHD Graphics in processor is disabled
Operating System
Operating System**[1]
- Windows® 11 Pro
- Windows 11 Home
- Windows 11 Home Single Language
- Windows 10 Pro 64
- Windows 10 Home 64
- Windows 10 Home 64 Single Language
- No operating system
Notes:
- 1 :Some features may not be supported on the system with Linux preload, including but not limited to Intel RST RAID, Human Presence Detection, etc.
Graphics
Graphics**[1]
| Graphics | Type | Memory | Connector | Max Resolution | Key Features |
| AMD Radeon™ RX 6800XT | Discrete | 16GB GDDR6 | 1x HDMI® 2.1, 2x DP 1.4,1x USB-C® 3.2 Gen2 | 7680*4320@120Hz(HDMI), 7680x4320@60Hz(DP) | DirectX® 12 |
| NVIDIA® GeForce RTX™ 2080 SUPER | Discrete | 8GB GDDR6 | 1x HDMI 2.0b, 3x DP 1.4 | 7680x4320@60Hz(DP) | DirectX 12 VR ready |
| NVIDIA GeForce RTX 2060 CD | Discrete | 6GB GDDR6 | 1x HDMI 2.0b, 3x DP 1.4 | 4096x2160@60Hz(HDMI), 7680x4320@60Hz with DSC(DP) | DirectX 12 |
| NVIDIA GeForce RTX 2070 CD | Discrete | 8GB GDDR6 | 1x HDMI 2.0b, 3x DP 1.4 | 7680x4320@60Hz(DP) | DirectX 12 VR ready |
| NVIDIA GeForce RTX 2070 SUPER | Discrete | 8GB GDDR6 | 1x HDMI 2.0b, 1x USB-C Gen 2, 3x DP 1.4 | 7680x4320@60Hz(DP) | DirectX 12 VR ready |
| NVIDIA GeForce RTX 3060 | Discrete | 12G GDDR6 | 3x DP 1.4a, 1x HDMI 2.1 FRL | 7680x4320@60Hz(HDMI), 7680x4320@60Hz(DP) | DirectX 12 |
| NVIDIA GeForce RTX 3060 Ti | Discrete | 8G GDDR6 | 3x DP 1.4a, 1x HDMI 2.1 FRL | 7680x4320@60Hz(HDMI), 7680x4320@60Hz(DP) | DirectX 12 |
| NVIDIA GeForce RTX 3070 | Discrete | 8G GDDR6 | 3x DP 1.4a, 1x HDMI 2.1 | 7680x4320@60Hz(HDMI); 7680x4320@60Hz(DP) | DirectX 12 |
| NVIDIA GeForce RTX 3070 Ti | Discrete | 8G GDDR6X | 3x DP 1.4a, 1x HDMI 2.1 | 7680x4320@60Hz(HDMI); 7680x4320@60Hz(DP) | DirectX 12 |
| NVIDIA GeForce RTX 3080 | Discrete | 10G GDDR6X | 3x DP 1.4a, 1x HDMI 2.1 | 7680x4320@60Hz(HDMI); 7680x4320@60Hz(DP) | DirectX 12 |
| NVIDIA GeForce RTX 3080 Ti | Discrete | 12G GDDR6X | 3x DP 1.4a, 1x HDMI 2.1 | 7680x4320@60Hz(HDMI); 7680x4320@60Hz(DP) | DirectX 12 |
Notes:
- 1 :The information of integrated graphics are not applicable for the models without integrated graphics (for the details, please refer to processor section)
Monitor Support
Notes:
- 1 :Ports may vary by the discrete graphics.
Chipset
Memory
Notes:
- 1 :The max memory is based on the test results with current Lenovo® memory offerings. The system may support more memory as the technology develops.
- 2 :Installed memory is actually 3200MHz or 3600MHz, but may run at 2933MHz depending on the memory support capability of processor
Storage
Storage Support[1]
Up to six drives, 2x 3.5" HDD + 2x 2.5'' HDD + 2x M.2 SSD
• 3.5" HDD up to 2TB
• 2.5" HDD up to 1TB
• M.2 SSD up to 1TB
Storage Type***
| Disk Type | Interface | RPM | Security |
| 3.5" SATA HDD | SATA 6Gb/s | 7.2K | - |
| M.2 2280 SSD | PCIe® NVMe®, PCIe 3.0 x4 | - | - |
| M.2 2280 SSD | PCIe NVMe, PCIe 4.0 x4 | - | - |
Notes:
- 1 :The storage capacity supported is based on the test results with current Lenovo storage offerings. The system may support larger storage as the technology develops.
Removable Storage
Multi-Media
Power Supply
Design
Input Device
Keyboard**
- Lenovo Calliope Keyboard (USB connector), black
- Lenovo USB Keyboard (USB connector), black
- No keyboard
Mechanical
Cooling System (Fan & Cooler)***
- (Optional) 1x front system fan, 1x rear system fan for airflow or liquid
- (Optional) 1x front system fan, 1x rear system fan with ARGB
- (Optional) 2x top system fan with ARGB, 3x front system fan with ARGB, 1x rear system fan with ARGB
- (Optional) 3x front system fan with ARGB, 1x rear system fan with ARGB
- (Optional) 150W side flow Air-Cooler or 200W Liquid-Cooler
Notes:
- 1 :The system dimensions may vary depending on configurations.
- 2 :The system weight is approximate and based on results in Lenovo lab, which varies depending on the source of component, variance of the distribution of each component, and manufacturing process. It may not be the exact weight for each specific model.
Connectivity
Network
Notes:
- 1 :Bluetooth 5.2 is hardware ready but may run at a lower version due to OS limitations.
Ports[1]
Rear Ports[2]
- 1x USB-C 3.2 Gen 2 (support data transfer and 5V@3A charging)
- 4x USB 2.0
- 2x USB 3.2 Gen 1
- 1x USB 3.2 Gen 2
- 1x Ethernet (RJ-45)
- 1x line-in (blue)
- 1x line-out / front output (green)
- 1x microphone in (pink)
- 1x centre and subwoofer combine output (orange)
- 1x side surround output (grey)
- 1x rear surround output (black)
- 1x power connector
Notes:
- 1 :The transfer speed of following ports will vary and, depending on many factors, such as the processing speed of the host device, file attributes and other factors related to system configuration and your operating environment, will be slower than theoretical speed. USB 2.0: 480 Mbit/s; USB 3.2 Gen 1 (SuperSpeed USB 5Gbps, formerly USB 3.0 / USB 3.1 Gen 1): 5 Gbit/s; USB 3.2 Gen 2 (SuperSpeed USB 10Gbps, formerly USB 3.1 Gen 2): 10 Gbit/s; USB 3.2 Gen 2x2 (SuperSpeed USB 20Gbps): 20 Gbit/s; Thunderbolt™ 3/4: 40 Gbit/s
- 2 :For video ports on discrete graphics, please see graphics section
Security & Privacy
Service
Warranty[1]
Base Warranty**
- 1-year courier or carry-in service
- 1-year mail-in service
- 1-year limited onsite service
- 2-year courier or carry-in service
- 3-year courier or carry-in service
- OB
Notes:
- 1 :The warranty upgrades may be bundled with some models, please check the "Included upgrade" column in the specific model's configurations. For more service extensions, please go to https://smartfind.lenovo.com/. To learn more details of warranty policy, please access https://pcsupport.lenovo.com/warranty.
Environmental
Certifications
Green Certifications[1]
Notes:
- 1 :The items listed under the "Green Certifications" section may not only refer to certification but also registration or self-declaration.
- Feature with ** means that only one offering listed under the feature is configured on selected models.
- Feature with *** means that one or more offerings listed under the feature could be configured on selected models.
- Lenovo reserves the right to change specifications or other product information without notice. Lenovo is not responsible for photographic or typographical errors. LENOVO PROVIDES THIS PUBLICATION “AS IS,” WITHOUT WARRANTY OF ANY KIND, EITHER EXPRESS OR IMPLIED, INCLUDING THE IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. Some jurisdictions do not allow disclaimer of express or implied warranties in certain transactions, therefore this disclaimer may not apply to you.
- The specifications on this page may not be available in all regions, and may be changed or updated without notice.
